ANSI/ASME B18.2.1Titanium grade2 capscrew 3/8"-16 UNC X 4" c/w hex boltsNut price
1. Titanium hex bolts nut
Titanium fasteners have always been the ultimate statement of performance and status.
At almost half the weight of steel, along with high strength and a machined finish that
can never rust or tarnish, it's easy to see why they are so widely desired.
Discovered: 1791
Melting point: 3,034°F (1,668°C)
Symbol: Ti
Electron configuration: [Ar] 3d2 4s2
Atomic number: 22
Boiling point: 5,948°F (3,287°C)
2. Drawing ANSI/ASME B18.2.1 standard
3. Details picture
| Item Name | Gr2 titanium 3/8"-16 UNC X 4" c/w hex bolts Nut |
| Material | Pure Titanium (Gr2) |
| Thread | UNC |
| Standard | ANSI/ASME B18.2.1 |
| Specification | Screw / bolt: M2—M64*L6—300mm (or as your inquired ) Nut: M2—M30 Washer: M2—M30 Non-standard and special size is available according to your drawing or requirement |
| Surface Treatment | Polishing |
| Color | Ti natural |
| Features | light weight, acid and alkali resistance, anti-corrosion, excellent mechanical strength etc. |
| Applications | Equipment accessories: airplane, ship, bicycle, motorcycle, auto, medical, chemical, wheel, sports, anchor, weapon, etc. |
Chemical composition (Wt%)
| Grade | Fe max | O max | N max | C max | H max | Pd | Al | Bal |
| Gr2 | 0.3 | 0.25 | 0.03 | 0.1 | 0.015 | - | - | Ti |
Physical Properties (Min)
| Grade | Alloy Composition | Tensile Strength | Yield Strength | Elongation min % |
| ksi | Mpa | ksi | Mpa | |
| Gr2 | Unalloyed Ti ("Pure") 50A -CP2 | 58 | 400 | 40 | 275 | 25 |
Product Tags:
|
|
Grade 2 Titanium Cap Screw , 3/8"-16 UNC X 4" C/W Hex Bolts And Nuts Images
|
